Product Description
The Quingo Ultra is the newest and smallest edition to the Quingo 5-wheel mobility scooter range. This portable scooter is easy to dismantle and straightforward to transport, taking less than 60 seconds to be loaded in to the boot of even a small car. Due to its lightweight aluminium chassis, it is easy to lift the individual components. Ideal indoors or out, it can be used in shopping centres and for trips to small local shops or keeping in touch with family and friends.
Unlike other portable mobility scooters, the Quingo Ultra allows for plenty of leg-room thanks to it's unique 5-wheel design and promotes an ergonomic seating position.
The unique 5 wheel stability system enjoyed by Quingo scooters maintains the manoeuvrability, superior driving position and posture benefits of a 3 wheel mobility scooter while implementing the stability and safer cornering characteristics of a 4 wheel scooter. Additionally Quintell™ Adaptive foot-plates allow individual adjustment in multiple planes assuring the most natural and comfortable ride.
This scooter comes standard with 2 x 15ah batteries, which gives you a travel range of 15km, however has the capacity to easily add 2 additional batteries to the battery box, to double the range, reaching 29km per charge. Please note, the battery extender is an optional extra.
Specifications
ISO Certification |
7176:2008,7176-5:2008, 7176-7:1998, 7176-2:2012, 7176-11:1992 |
Adjustable Armrests |
Yes |
Adjustable Backrest |
No |
Adjustable Headrest |
No |
Adjustable Seat Height |
Yes |
Adjustable Tiller Angle |
Yes |
Adjustable Tiller Height |
No |
Anti-Tip Mechanism |
Kerb Master & Anti breach technology |
Armrests |
Yes |
Battery |
2 x 15Ah SLA - Optional upgrade additional two 15.AH SLA |
Battery Range |
up to 15km or up to 29km with battery extension |
Battery Weight |
4.5kg x 2 (4 with battery extension pack) |
Dimensions |
1200 x 580 x 930 |
Distance between armrests |
450 - 600 |
Drive Wheel |
229mm |
Ground Clearance |
50mm |
Heaviest Part |
17.8kg |
High / Low Speed Selection |
No |
Lights |
Front and rear |
Lithium Battery |
No |
Maximum Speed |
6.4kmh |
Motor |
DC 24V 250W |
Number of Components |
3 + batteries |
Seat Dimensions |
580mm x 370mm |
Seat height from Deck |
380 - 440mm |
Seat height from Floor |
540 - 590mm |
Seat Padding |
Medium |
Slope ability |
6° |
Suspension |
No |
Swivel Seat |
Yes |
Turning Radius |
1040mm |
Tyres |
Pneumatic |
Weight Capacity |
140kg |
Weight with Battery |
62kg |
Weight without Battery |
53kg |
Wheel to Wheel |
750mm |
